Digitalization
- Rapid replacement of different cutting images by computer , not only meets the personalized demands , but suits for short run ( digital ) printing jobs and post-press processing of large format imposition printing.
Individualization
- It releases the designers' inspiration and uses the software to directly complete the 3D three-dimensional display on the computer to avoid design defects and errors in the production process. Because there is no limitation of knife mold tools, the designer's creative space can be greatly expanded.
High Precision
- Automatic laser cutting and engraving guarantee zero vibration deviation . Video capture technology minimizes the sheet feeding clearance , meanwhile ensures cutting precision.
High Efficient
- To replace and upgrade traditional mechanical die cutting by laser cutting, save the time for producing and adjusting of traditional cutting dies.
Affordable Cost
- Model to cut graphics and characters arbitrarily is controlled by computer , mechanical cutting die is not required , operation and maintenance cost is less.
Deviation Correction System
- The deviation correction system can correct the deviation of various coiled materials, and is combined with encoder, sensor and other deviation correction components to help the equipment operate efficiently and stably.
Tension Control System
- The tension controller can directly set the tension value required to be controlled, with the function of coil diameter calculation.
Coding Control System
- The encoder converts the displacement into counting pulses, and uses the number of pulses to represent the displacement to ensure the accuracy of laser die cutting.
| Technical Specifications : | MK 360R |
| Design Type: | Roll to Roll / Roll to sheet |
| Max. Sheet Size: | 360mm |
| Application Materials: | Self-Adhesive Paper,PP, pet, paper, etc |
| Light Source: | CO₂ |
| Laser energy: | 180W/300W |
| Positioning Method: | Color Code Sensor+Auto Deviation Correction |
| Max. Scan Range: | 350mmX350mm |
| Input File: | PLT, DXF |
| Power Supply: | AC380V+N+PE 50Hz 10KW |
| Working Environment: | T25±2°C, RH40%-60% |
| Net Weight: | 2000kg |
| Machine Dimension: | 3600x 2260x 1740mm |
| Optional: | Online Sheeter |
For more information, please download the PDF brochure, or click "Contact" to subscribe
